SITUS Protocol: Sensor-Integrated Trust Using Spatial Entropy — Authentication Bound to Physical Reality

The Missing Dimension in Authentication

Every authentication system deployed today answers one question: "Who are you?"

Passwords prove you know a secret. Biometrics prove you have a specific body. Hardware tokens prove you possess a specific device. Behavioral biometrics — like KAVI Protocol's Surprise Signature — prove you exhibit a specific behavioral pattern. Each method verifies identity with increasing sophistication.

But none of them answer a second, equally critical question: "Where are you, right now, in the physical world — and can you prove it?"

This gap is not theoretical. A compromised VPN credential works from Moscow as easily as from the authorized office in Virginia. A stolen biometric template can be replayed from any location. Even behavioral biometrics, while significantly harder to forge, operate independently of physical context. The attacker doesn't need to be where the victim is — they only need to be the victim, digitally.

SITUS Protocol — Sensor-Integrated Trust Using Spatial Entropy — closes this gap. It introduces a cryptographic primitive we call an Environmental Entropy Vector (EEV), which binds every authentication event to the unrepeatable physical context in which it occurs. The result: credentials that are not only non-transferable but non-relocatable.

Core Insight: Physical Entropy as a Cryptographic Primitive

At any given moment, your device exists in a unique physical context defined by dozens of measurable environmental signals:

• RF environment: The specific set of WiFi networks visible, their signal strengths, and their relative positions. The Bluetooth devices discoverable. Cellular tower IDs and signal characteristics.
• Acoustic environment: The ambient noise spectrum — HVAC hum frequency, traffic patterns, human activity. Not the content of sounds, but their spectral fingerprint.
• Inertial environment: Accelerometer noise floor, gyroscope drift patterns, device orientation relative to gravity. Even a stationary device has a characteristic vibration signature determined by the surface it rests on.
• Atmospheric environment: Barometric pressure, ambient light wavelength distribution, temperature (via battery charging characteristics).
• Electromagnetic environment: Magnetic field vector (influenced by building structure, nearby electronics, geographic location).
• Network environment: Latency fingerprints to distributed reference servers, packet jitter characteristics, route topology.

Individually, each signal carries limited entropy. An attacker could spoof GPS coordinates or fabricate a WiFi scan. But the cross-correlation of all signals simultaneously creates a context that is:

1. High-entropy: The combined state space across all sensors is astronomically large
2. Internally consistent: Signals must agree — the WiFi networks must match the geographic region implied by cell towers and network latency
3. Temporally unique: The exact configuration never repeats, because environmental conditions continuously change
4. Physically bound: Replicating the context requires physical presence in the same location

SITUS formalizes this environmental context into a cryptographic primitive and integrates it into the authentication protocol.

Protocol Architecture

SITUS consists of five components that work together to bind identity to physical context:

1. Entropy Harvesting Layer (EHL)

The EHL runs on the authenticating device and collects environmental signals from all available sensors. It produces an Environmental Entropy Vector (EEV) — a structured, timestamped representation of the device's physical context.

The EEV is not a raw sensor dump. Each signal source is processed through a feature extraction pipeline that:

• Normalizes sensor data to device-independent representations
• Extracts stable features (WiFi BSSID set) and volatile features (signal strength fluctuations)
• Computes an entropy density score for each source, indicating how much randomness it contributes
• Strips privacy-sensitive content (e.g., audio is reduced to spectral features, never stored as recordings)

The resulting EEV is a fixed-length vector E = (e₁, e₂, ..., eₙ) where each eᵢ represents the processed output of one entropy source, accompanied by its entropy density score H(eᵢ).

2. Commitment Engine (CE)

The Commitment Engine implements the critical commit-before-challenge protocol that prevents an attacker from fabricating environmental data after seeing the authentication challenge.

The protocol flow:

1. Device harvests EEV and computes commitment: C = H(EEV ‖ nonce)
2. Device sends commitment C to server (without revealing EEV)
3. Server generates random challenge R and sends it to device
4. Device computes context-bound signature: σ = Sign(sk, R ‖ EEV ‖ timestamp)
5. Device sends (σ, EEV, nonce, timestamp) to server
6. Server verifies commitment, signature, and EEV validity

The commitment is essential. Without it, an attacker who intercepts the challenge could fabricate an EEV and compute a valid signature. With the commitment, the EEV is fixed before the challenge is known — the attacker cannot retroactively adjust the environmental data.

3. Cross-Sensor Consistency Validator (CSCV)

The CSCV is the server-side component that determines whether a submitted EEV is genuine or fabricated. It doesn't need to know the expected environment — it verifies internal consistency.

Consistency checks include:

Check	What It Validates	Attack It Defeats
RF-Geo correlation	Visible WiFi BSSIDs are consistent with IP geolocation and cell tower data	Remote replay with spoofed GPS
Acoustic-Inertial correlation	Ambient noise patterns match accelerometer vibration (e.g., both detect traffic)	Selective sensor spoofing
Temporal consistency	Sensor readings change at physically plausible rates between consecutive authentications	Pre-recorded environment injection
Entropy density	Each source contributes minimum expected entropy (fabricated data tends to be either too uniform or too random)	Synthetic data generation
Network-Physical correlation	Network latency to reference servers is consistent with claimed physical location	VPN/proxy-based location spoofing

The CSCV uses a learned model (trained on legitimate authentication events) to score consistency. The model outputs a Context Authenticity Score (CAS) between 0 and 1. Authentication requires CAS above a risk-dependent threshold.

4. Adaptive Threshold Module (ATM)

Not every authentication requires the same level of environmental proof. The ATM adjusts requirements based on the risk level of the requested operation:

Risk Level	Required Entropy Sources	Minimum CAS	Example Operations
Low	2+ sources (e.g., WiFi + accelerometer)	0.6	Reading email, viewing dashboards
Medium	4+ sources including RF environment	0.75	Code deployment, document access
High	6+ sources with geo-network correlation	0.85	Financial transactions, admin access
Critical	All sources + multi-device correlation	0.95	Key ceremony, infrastructure changes

At the Critical level, SITUS requires multi-device environmental correlation: two or more devices belonging to the user (e.g., phone and laptop) must independently report consistent environmental context. An attacker would need to compromise multiple devices and be physically present in the victim's environment — a dramatically harder attack.

5. Temporal Decay Function (TDF)

An authenticated session's validity decays as a function of environmental change rate. The TDF continuously monitors how rapidly the EEV is evolving:

• Static environment (office desk): Session validity up to 15 minutes before re-authentication
• Slowly changing (walking through a building): Session validity ~3 minutes
• Rapidly changing (in a moving vehicle): Session validity ~30 seconds
• Discontinuous change (device appears to teleport): Immediate session termination

The decay function is: V(t) = V₀ · e^(-λ · ΔE(t)), where ΔE(t) is the cumulative environmental change since the last authentication and λ is the risk-adjusted decay constant. When V(t) drops below the threshold, re-authentication is required.

This makes session hijacking ineffective. Even if an attacker captures an active session token, the session terminates as soon as the environmental context diverges — which happens immediately if the attacker is in a different physical location.

Security Analysis

Threat Model

SITUS assumes a powerful adversary who:

• Has stolen the user's private key
• Can observe all network traffic (active MITM)
• Can spoof individual sensors (GPS, WiFi scan results)
• Has access to commodity hardware and software
• Is not physically present at the user's location

Attack Resistance

Credential Theft (Remote Attacker): Possessing the private key is insufficient. The attacker cannot produce a valid EEV because they are not in the victim's physical environment. Fabricating an EEV requires simultaneously spoofing 6+ sensor channels with internal consistency — the cross-sensor validation makes this computationally and physically impractical.

Replay Attack: Each EEV is timestamped and committed before the challenge is issued. The server maintains a Bloom filter of EEV commitments, rejecting any commitment seen before. Environmental entropy ensures that even two authentications from the same desk one minute apart produce different EEVs.

Sensor Spoofing: An attacker can spoof one or two sensors (e.g., GPS, WiFi scan). But the CSCV cross-validates all sensors against each other. Spoofing GPS while leaving WiFi and cell tower data authentic creates detectable inconsistencies. Spoofing all sensors consistently requires knowledge of the victim's exact physical environment — which requires physical presence, defeating the purpose of the remote attack.

Man-in-the-Middle: The commit-before-challenge protocol ensures that the EEV is fixed before the challenge is revealed. An MITM cannot modify the EEV to match a different environment without invalidating the commitment. The MITM also cannot relay the authentication in real-time because the temporal decay function detects the additional network latency.

Insider Threat (Physical Proximity): SITUS does not protect against an attacker who is physically present at the same location as the victim and has stolen the victim's private key. This is by design — if the attacker is already physically present and has the credential, they are operationally indistinguishable from the legitimate user. This is the boundary condition of the protocol, and it is explicitly narrower than the threat models of password-based or token-based systems.

Comparison with Existing Approaches

Approach	Proves Identity	Proves Location	Replay-Resistant	Non-Transferable	Non-Relocatable
Passwords	Weakly	No	No	No	No
Hardware Tokens (FIDO2)	Yes	No	Yes	Partially	No
Behavioral Biometrics (KAVI)	Yes	No	Yes	Yes	No
GPS-based Geofencing	No	Weakly (spoofable)	No	N/A	Weakly
SITUS Protocol	Yes (with KAVI)	Yes (multi-sensor)	Yes (commit-challenge)	Yes	Yes

SITUS is designed to complement, not replace, identity-proving protocols. The optimal deployment combines KAVI Protocol (proving who you are through behavioral signatures) with SITUS (proving where you are through environmental entropy). Together, they create authentication that is simultaneously non-transferable and non-relocatable — a stolen credential is useless because the attacker cannot replicate the victim's behavior or physical context.

Implementation Considerations

Privacy

SITUS collects extensive environmental data. Privacy protection is built into the protocol:

• Feature extraction, not raw data: Audio is reduced to spectral features. WiFi scans retain BSSIDs but not SSIDs. No personally identifiable information is included in the EEV.
• Client-side processing: Raw sensor data never leaves the device. Only the processed EEV and its commitment are transmitted.
• Server-side amnesia: The server stores EEV commitments (for replay prevention) but not the EEVs themselves. After verification, the EEV is discarded.
• Differential privacy: Noise is added to individual sensor readings before inclusion in the EEV, preventing the server from extracting precise location data while maintaining sufficient entropy for verification.

Sensor Availability

Not all devices have all sensors. SITUS degrades gracefully:

• The ATM adjusts requirements based on available sensors
• Minimum viable authentication requires at least 2 independent entropy sources
• Desktop computers without accelerometers or microphones can use network latency fingerprinting + WiFi environment as minimum sources

Battery and Performance

Continuous sensor polling drains batteries. SITUS mitigates this through:

• Event-driven harvesting: Full EEV collection only at authentication events, not continuously
• Lightweight monitoring: Between authentications, only low-power sensors (accelerometer, WiFi scan) are monitored for the TDF
• Cached features: Slowly-changing features (barometric pressure, magnetic field) are cached and refreshed at longer intervals

Applications

Critical Infrastructure Access

Power grids, water treatment facilities, and military systems require that operators are physically present at authorized locations. SITUS provides cryptographic proof of physical presence without invasive surveillance — the system knows where you are without watching you.

Remote Work Policy Enforcement

Organizations that require work from approved locations (home office, corporate office, approved co-working spaces) can verify compliance without screen recording or GPS tracking. SITUS proves you're in an approved environment without recording what you're doing in it.

Financial Transaction Authorization

High-value transactions can require environmental consistency — the transaction must originate from an environment the user has previously authenticated from. A $500,000 wire transfer initiated from an unfamiliar environmental context triggers additional verification.

Digital Evidence Integrity

Law enforcement and legal proceedings require proving that digital evidence was collected at a specific time and place. SITUS can embed environmental context into evidence metadata, providing cryptographic proof that a photograph was taken at a specific location — not just GPS coordinates (which can be spoofed), but a full environmental fingerprint.

IoT Device Attestation

IoT devices deployed in specific locations (security cameras, industrial sensors, medical devices) can use SITUS to prove they haven't been physically relocated. A security camera that's been moved to a different location will fail environmental attestation, alerting administrators to potential tampering.

Formal Protocol Specification

Setup Phase

During enrollment, the user's device performs n authentication events from authorized locations. These establish a baseline environmental profile — not a fixed template, but a model of the user's typical environmental characteristics and their natural variance.

Authentication Phase

1. Client:  E ← EHL.harvest()               // Collect environmental entropy
2. Client:  nonce ← random(256)              // Generate random nonce
3. Client:  C ← SHA3-256(E ‖ nonce)          // Compute commitment
4. Client → Server:  C                        // Send commitment
5. Server:  R ← random(256)                   // Generate challenge
6. Server → Client:  R                        // Send challenge
7. Client:  σ ← Ed25519.Sign(sk, R ‖ E ‖ t)  // Sign challenge + context
8. Client → Server:  (σ, E, nonce, t)         // Send signature + context
9. Server:  Verify SHA3-256(E ‖ nonce) == C   // Check commitment
10. Server: Verify Ed25519.Verify(pk, σ, R ‖ E ‖ t)  // Check signature
11. Server: Verify |t - t_server| < Δt_max    // Check timestamp freshness
12. Server: Verify C ∉ BloomFilter            // Check replay
13. Server: CAS ← CSCV.validate(E)           // Cross-sensor consistency
14. Server: Verify CAS ≥ threshold(risk)      // Check context authenticity
15. Server: BloomFilter.insert(C)             // Record commitment
16. Server: Return (session_token, V₀, λ)     // Issue decaying session

Session Maintenance

Every interval Δt:
1. Client:  E' ← EHL.harvest_lightweight()   // Low-power sensor check
2. Client:  ΔE ← distance(E_last, E')        // Compute environmental drift
3. Client:  V(t) ← V₀ · e^(-λ · ΔE_cumulative)  // Compute session validity
4. If V(t) < threshold: trigger re-authentication
5. If ΔE > discontinuity_threshold: terminate session immediately

Conclusion

Authentication has always been about identity — proving who you are. SITUS Protocol adds a second dimension: proving where you are, with the same cryptographic rigor we apply to identity.

By formalizing environmental entropy as a cryptographic primitive and building a commit-before-challenge protocol around it, SITUS creates authentication that is non-relocatable — credentials that work only in the physical context where they're used. Combined with behavioral authentication like KAVI Protocol, this creates a system where an attacker must simultaneously replicate the victim's behavior and physical environment — a constraint that makes remote credential exploitation structurally impossible.

The physical world has entropy that the digital world cannot fake. SITUS turns that entropy into a security guarantee.

Resources

• Whitepaper (PDF): DOI: 10.5281/zenodo.19024600
• GitHub Repository: github.com/singhpratech/SITUS
• Zenodo Record: zenodo.org/records/19024600
